Description
Technical Specifications
| Phase | Three Phase |
| Measuring Energy Range | 0 kWh to 9999999.999 kWh |
| Output Voltage | 85 V to 270 V AC (L-N), 85 V AC to 480 V AC (L-L) |
| Display Type | Digital nnly |
| Accuracy Class | Class 1/0.5S |
| Communication Protocol | LoRaWAN + Modbus |
| Freqeuency | 45 Hz to 65 Hz |
| Max Current | 100 A |
| Usage | Measuring energy consumption and other electric parameters |
| Measuring Harmonic | Yes |
| Bi-Directional Measuring | Yes |
| Installation | 1.37 in (3.5 cm) din rail kWh meter |
| Operating Temperature | -13 °F to 131 °F (-25 °C to 55 °C) |
| Dimensions | 2.83 in × 3.93 in × 2.59 in (7.2 cm × 10 cm × 6.6 cm) |
