| Compliance |
IEC61010-1 for live systems up to 150 V CAT IV with fused test lead set |
| Output Pulse |
5 volts peak to peak into open circuit |
| Pulse Widths |
Determined by range and cable, set with 3 user-selectable steps in Manual mode |
| Velocity Factor |
Variable from 0.2 to 0.99 in steps of 0.01 |
| Battery Type |
Five LR6 (AA) type batteries, Manganese alkali or nickel metal-hydride cells |
| TX Null |
Automatic |
| Power Down |
Automatic after 5 minutes with no key press |
| Backlight |
Stays on for 1 minute with no key press |
| Range |
30 ft, 75 ft, 300 ft, 750 ft, 3000 ft, 7500 ft, 15000 ft (10 m, 25 m, 100 m, 250 m, 1000 m, 2500 m, 5000 m) |
| Accuracy |
±1% of range + pixel at 0.67 VF (conditional on correct velocity factor) |
| Resolution |
0.32 ft (0.1 m) |
| Input Protection |
1% of range |
| Battery Life |
Up to 14 hours (typical) |
| Display |
256 x 128-pixel Graphics LCD |
| Dimensions |
9.05 in x 4.52 in x 1.88 in (23 cm x 11.5 cm x 4.8 cm) (LBD) |
| Weight |
1.32 lb. (0.6 kg) |
