| Battery Type |
Rechargeable Li-ion battery. |
| Battery Life |
12 hours typical. |
| Near-End Fault Location |
2 ns pulse capability. |
| Resolution |
1% of range. |
| Display Contrast |
Adjustable. |
| Display |
800 x 480 pixel color graphics LCD, readable in outdoor environments. |
| Range |
Up to 65,616 ft (20,000 m) with a minimum resolution of 4 in (0.1 m). |
| Trace Memory |
Stores up to 100 traces on board. |
| PC Connection |
USB connection for uploading/downloading traces. |
| PC Software |
Includes “TraceXpert” analysis tool. |
| Circuit Compatibility |
Telecom TNV-3 or 150V CAT IV power circuits. |
| Output Impedance |
Selectable: 25, 50, 75, 100, and 125 Ω. |
| Operating Temperature |
5°F to 122°F (-15°C to 50°C). |
| Dimensions |
11.4 in x 7.5 in x 2.2 in (29 cm x 19 cm x 5.5 cm). |
| Weight |
3.8 lbs (1.7 kg). |
