| Features |
UHF RFID Reading, GPRS or 3 G WCDMA, Wi-Fi, BT, GPS |
| Structure |
Rugged, dust-resistant, high-precision, high-speed |
| CPU |
Cortex-A7 1.3 GHz Quad Core |
| Memory |
1 G RAM or 4 GB FLASH |
| Expansion Memory |
Supports max 32G Micro SD (TF) card |
| Interfaces |
USB Micro-B, RS-232 (TTL), DC adapter port |
| Touch Screen |
4 inch WVGA backlight, 480 x 800 TFT-LCD, capacitive dual touch |
| Audio |
0.5 W speaker, built-in microphone |
| Battery |
Rechargeable Li-ion polymer (3.7 V or 3,200 mAh) + Pistol battery (5,200 mAh) |
| Expansion Slots |
SIM or Micro SD (TF) card |
| Keyboard |
3 Function buttons, 3 side buttons |
| Operating System |
Android 4.4.2 with English OS |
| Programming Environment/Tool |
Eclipse |
| RFID (LFF) |
125 KHz or 134.2 KHz |
| RFID Module |
R2000 |
| Protocol |
18000-2; 11784 or 11785 |
| Antenna |
Horizontal Linear polarization (2dBi) |
| Max Power |
1 W (+10 dBm ~ +30 dBm) |
| Max Reading/Writing Range |
Up to 14.76 ft (4.5 m) (depending on tags and environment) |
| Wi-Fi |
IEEE802.11 b or g or n, internal antenna |
| Bluetooth Support |
v2.1+EDR or 3.0+HS |
| 3G Support |
WCDMA or HSDPA or HSPA+: 850 or 1900 or 2100 MHz, compatible with GPRS |
| GPS |
Embedded A-GPS |
| AC Adapter |
Input: 100 to 40 V or 50 to 60 Hz; Output: 5.0 V or 2.0 A |
| Optional Features |
Barcode or Fingerprint function (additional cost) |
| Net Size |
6.02 in x 2.95 in x 1.14 in (15.3 cm x 7.5 cm x 2.9 cm) |
| Weight |
10.76 oz (305 g) |
