| CPU |
J6412 Quad-Core 2.0GHz, Burst to 2.6 GHz CPU |
| Memory |
1 X DDR4 3200 SO-DIMM memory, supports up to 16GB |
| SDD |
1 X mSATA HDD installation and support 2.5 inch (6.35 cm) HDD installation |
| LCD |
12.1 inch(30.73cm), 1024 x 768 resolution; MTBF: 50000 hours, brightness 300cd to m optional |
| DC IN |
1 X 2PIN Phoenix Power Input Holder (9 to 36V Wide Voltage Input) |
| GPIO+COM |
2 X 8 PIN Phoenix Power Input Dock (including 4DI4DO+COM3 or 4,RS-232 |
| COM |
2*DB9 (COM1 or 2 ,pin #9 optional powered RI or 5V or 12V, COM1 dip switch optional RS232 or 422 or 485 mode, COM2 dip switch optional RS232 or 485mode) |
| HDMI |
1 X HDMI |
| LAN |
2 X Intel I210AT Gigabit LAN card |
| USB |
4 X USB3.0 (double layer TYPE-A interface) |
| Audio |
1 X 2-in-1 audio interface |
| PWR Switch |
1 X PWR SW + PWR LED |
| Material |
High quality aluminum alloy, Fanless passive cooling |
| Installation |
Embedded, Wall, Desktop Bracket |
| Operating Environment |
14°F to 140°F (-10 to 60°C), humidity: 5% to 95%, non-condensing |
| Storage Environment |
-4°F to 185°F (-20 to 85°C), humidity: 5% to 95%, no condensation |
| Size |
Overall size: 12.24 in X 9.80 in X 2.30 in 311m X 249 mm X 58.5 mm |
| Weight |
Net weight 8.82 IB (4KG) |
