| Wavelengths |
1310/1550 nm, 1625 nm |
| Display |
9 in touchscreen with high visibility LCD 800×480 |
| Internal Memory |
1 GB |
| Wi-Fi/Bluetooth |
Standard IEEE 802.11 b/g and bluetooth class 2 |
| Ethernet |
10/100/1000 MHz |
| USB |
2x USB 2.0 ports |
| Power Meter Power Level |
+10 dBm to -60 dBm |
| Power Meter Calibrated Wavelengths |
850, 1310, 1550nm |
| Connector Type (Power Meter) |
Universal push/pull (UPP) |
| Visual Fault Locator Wavelength |
635 nm ±15 nm |
| Visual Fault Locator Output Power level |
< 1mW |
| Visual Fault Locator Laser Safety |
Class 2 laser |
| Talk Set Dynamic Range |
32 dB typical |
| Battery Type |
Standard removable liIon |
| AC/DC Adapter |
Input 100-250 V, 50-60 Hz; Output 12-15 V DC/3.7A |
| Electrical Safety |
EN 60950 compliant |
| Operation Time |
Up to 16 hours telcordia GR-196-CORE |
| Dynamic Range |
40/40/38 dB |
| Humidity (Non-Condensing) |
95% |
| Operating Temperature Range (No Option) |
-4 °F to 122 °F (-20 °C to 50 °C) |
| Operating Temperature Range (All Options) |
32 °F to 104 °F (0 °C to 40 °C) |
| Storage Temperature Range |
-4 °F to 140 °F (-20 °C to 60 °C) |
| Mainframe with Two Modules & Battery |
11.1 in x 6.02 in x 3.8 in (28.2 cm x 15.3 cm x 9.7 cm) |
| Weight |
5.1 lb. with one module and battery (2.3 kg with one module and battery) |
