UHF RFID Car Parking System with Multiple Modes, 16.4 ft to 19.6 ft Read Range – Asset Track Pro

Efficient UHF RFID car parking system with automatic scanning, global frequency support, and multiple communication protocols. Ideal for versatile applications.

SKU: ATPUHF-488 Category:

Description

Features

  • Automatic scan Com Port or Network
  • Support firmware upgrade
  • Support Export Config or Import Config
  • Multiple country languages
  • Global frequency (860 MHz to 960 MHz)
  • Password mode
  • Read specify tag
  • Relay
  • Data cache (only TCP/IP communication: active mode support)
  • Multiple customizable communication protocols
  • Remote listening (only TCP/IP support)
  • RSSI



Technical Specifications

Frequency 902 MHz to 928 MHz (US) or 865 MHz to 868 MHz (EU)
Protocol EPC global UHF Class 1 Gen 2 or ISO 18000-6C
Built-In Antenna 6 dbi circular antenna
Output Power Range 0 dBm to 26 dBm (adjustable)
Read Range 16.4 ft to 19.6 ft (5 m to 6 m) (depends on antenna, tag and application)
Work Mode Active mode, trigger mode and answer mode (optional)
Interface RS232 or 485 or USB or WG26 or RELAY or TCP or IP or POE or WIFI or 4G (optional)
Power Supply 9 V to 36 V
Operating Temperature 14 °F to 131 °F (-10 ℃ to +55 ℃)
Storage Temperature -4 °F to 167 °F (-20 ℃ to +75 ℃)
Reader Size 7.48 in x 7.48 in x 1.18 in (190 mm x 190 mm x 30 mm)
Net Weight 1.65 lb (0.75 kg)
