| Frequency |
865 MHz to 868 MHz or 902 MHz to 928 MHz |
| Protocol |
EPC global UHF Class 1 Gen 2 or ISO 18000-6C |
| Material |
CNC Aluminium |
| Input Voltage |
DC 9 V to 24 V |
| Output Power |
0 dBm to 30.5 dBm |
| Operating System |
Linux 4.9.11 or Android 9.0 |
| RAM + ROM |
1G + 8G or 2G or 16G |
| Communication BT |
BT 4.0 |
| CPU |
IMX6DL (Dual) or IMX6Q (Quad), Automotive grade CPU |
| USB |
USB 2.0, Micro 5 PIN OTG, Support OTG function |
| POE Power |
25 W maximum, supports IEEE 802.3 protocol |
| HDMI |
HDMI D type interface, peak transmission speed 5 GB per sec, 1080 P or 720 P supported |
| WIFI |
SMA interface for external 2.4 G or 5G antenna |
| Size |
7.1 in X 6.2 in X 0.8 in (181.3 mm X 160 mm X 21 mm) |
| Weight |
2.6 lb (1.2 kg) |
