| Frequency |
865 MHz to 868 MHz or 920 MHz to 925 MHz |
| Protocol |
EPC C1 GEN2 or ISO 18000-6C |
| Memory |
16 GB ROM + 2 GB RAM |
| Battery |
Rechargeable li-ion polymer, 3.7 V, 4500 mAh |
| Data Communication |
4G WIFI Bluetooth Zigbee |
| Camera |
8 M auto-focus with LED flash |
| Display |
Gorilla 5.0 in (12.7 cm) TFT-LCD |
| Backlight |
LED backlight |
| Keypads |
3 TP keys, 6 function keys, 4 side buttons |
| Expansions |
2 PSAM, 1 SIM, 1 TF |
| CPU |
Quad A53 1.3 GHz quad-core |
| Operating System |
Android 5.1.1 |
| Storage |
2 GB RAM, 16 GB ROM, MicroSD |
| SDK |
HHW Software Development Kit |
| Language |
Java |
| Resolution |
8.0 megapixel |
| Lens |
Auto-focus with LED flash |
| Antenna Gain |
Circular antenna (2 dBi) |
| R Or W Range |
3.2 ft to 4.9 ft (1 m to 1.5 m) |
| Environment |
Android Studio or Eclipse |
| Humidity |
5 % RH to 95 % RH (non-condensing) |
| Drop Specification |
5 ft (1.5 m) drop to concrete across the operating temperature range |
| ESD |
±15 kv air discharge, ±8 kv direct discharge, ±8 kv indirect discharge |
| Working Temperature |
-4 °F to 122 °F (-20 ℃ to 50 ℃) |
| Storage Temperature |
-4 °F to 158 °F (-20 ℃ to 70 ℃) |
| Dimension |
6.6 in X 3.3 in X 0.9 in (170 mm X 85 mm X 23 mm) |
| Weight |
13.0 oz (370 g) |
