Description
Technical Specifications
| CPU | J3455 or J4205 |
| Memory | 4GB or 8GB |
| Storage | 128G or 256G SSD |
| Power Supply | DC 9 to 36V |
| WiFi-6 | Optional |
| 4G/5G | Optional |
| UPS | Optional |
| Operating System | Win10 or Linux centos7 or centos 8 or ubuntu |
| Installation | Wall-mounting or Back-mounting or Din-Rail |
| Graphics | Gen9 Graphics Engines (SoC integrated) |
| Storage | 1 x M.2 M-Key 2280 SATA3.0, 1 x SATA3.0 |
| External I or O | 1 x HDMI, resolution up to 3840 x 2160 @30Hz 2 x LAN (2 x i225-V) 3 x USB3.0, 1 x USB2.0 1 x RS-232, 1 x RS-485 (Serial Ports are optional) 1 x Micro SIM Phoenix 4PIN Power Connector |
| Internal I or O | 2 x USB2.0 (PIN Header) 1 x M.2 E-Key 2230 support Wi-Fi 6 1 x M.2 B-Key 3052 support 4G or 5G 1 x UPS (Optional) |
| Dimension | 6.77 x 4.92 x 2.46 in (172 x 125 x 62.5mm) |
