| Number of Channels |
Two channels |
| Display Mode |
10.1 in color LCD screen (1280×800) |
| Trigger Mode |
Automatically triggered |
| Sampling Interval |
0.025 μs to 2000 μs |
| Sampling Length |
512 to 2048 points multi-file optional |
| Receiving Sensitivity |
≤ 10 μV |
| Measurement Range of Sound Time |
0 μs to 4000000 μs |
| Amplitude Reading Range |
0 dB to 170 dB |
| Transmission Voltage |
125 V, 250 V, 500 V, 1000 V multiple options |
| Pulse Width of Emission |
0.1 μs to 100 μs |
| Storage Capacity |
16 G |
| Transfer Mode |
special U disk |
| Charging Power Supply |
AC100 to 240 V, 50/60 Hz, output 12.6 V DC, 3.0 A |
| Operating Temperature |
-4 ℉ to 140 ℉ (-20 ℃ to +60 ℃) |
| Depth Measurement Range |
0.19 in to 19.68 in (0.5 cm to 50 cm) |
| Width Measurement Range |
0.00039 in to 3.93 in (0.001 cm to 1 cm) |
| Host Volume |
11.14 in x 8.50 in x 1.61 in (28.3 cm × 21.6 cm × 4.1 cm) |
| Host Weight |
3.96 lb. (1.8 kg) |
