Description
Technical Specifications
| Working
Frequency |
CN standard（920 MHz to 925 MHz） |
| US standard（902 MHz to 928 MHz） | |
| Other frequency standards (customized) | |
| Protocol | ISO18000-6C (EPC GEN2) |
| ISO18000-6 | |
| Operation Mode | Fixed Frequency or FHSS or Software Programmable |
| Antenna Parameter | 2 dBi circularly polarized antenna (built-in) |
| Output Power | 12.5 dBm to 26 dBm (Adjustable by software) |
| Reader & Write Range | Reading Range (Max)：1.64 ft (0.5 m) (Related to the card or the environment) |
| Writing Range (Max)：0.66 ft (0.2 m) (Related to the card or the environment) |
|
| Working Mode | Active mode |
| Passive mode | |
| Answer mode (Not recommend) | |
| Interface | |
| Voltage | DC + 5 V |
| Data Interface | |
| USB to virtual keyboard input | |
| USB to virtual serial port (Customized) | |
| Accessories | |
| Cable | USB cable |
| SDK | Free SDK |
| Working Environment | |
| Working Temp | 4 °F to +131 °F (-20 ℃ to +55 ℃) |
| Storage Temp | -40 °F to +185 °F (-40 ℃ to +85 ℃) |
| Physical Parameter | |
| Size | 4.33 in x 2.75 in x 0.59 in (110 mm × 70 mm × 15 mm) |
| Net Or Gross Weight | 5.29 oz (150 g) or 8.82 oz (250 g) |
