Description
Technical Specifications
| Frequency | 13.56 MHz |
| Protocol | ISO or IEC 15693 |
| Working Voltage | DC +5 V or 3.3 V |
| Working Current | 100 mA |
| Communication Format | RS 232 |
| Baud Rate | 9600 bps or 115200 bps |
| Communication Speed | 106 Kbit per second |
| Read Range | 0 in to 3.94 in (0 mm to 100 mm) |
| Storage Temperature | -4 oF to 176 oF (-20 oC to 80 oC) |
| Working Temperature | 32 oF to 203 oF (0 oC to 95 oC) |
| Size | 1.54 in x 0.75 in x 0.04 in (39 mm x 19 mm x 1 mm) |
| Size (Antenna) | 2.95 in x 2.16 in x 0.04 in (75 mm x 55 mm x 1 mm) |
| Weight | 0.35 oz (10 g) |
