| Wavelengths (nm) |
850/1300, 1310/1550, 1310/1490/1550, 1625 |
| Dynamic Range (dB) |
21/19, 32/30, 38/36, 34/36 |
| Display |
5.6 in LCD touch screen PON ONTDR |
| Loss Threshold (dB) |
0.05 |
| Loss Resolution Ratio (dB) |
0.01 |
| Distance Scope (km) |
0.18 mi to 111 mi (0.3 km to 180 km) |
| Plus, Width (ns) |
5, 20, 40, 80, 160, 320, 640, 1280 or 5, 10, 20, 40, 80, 160, 320, 640, 1280, 2560, 5120, 10240/20480 |
| Event Blind Zone (m)³ |
32.8 ft (10 m) |
| Attenuation Blind Zone (m)³ |
65.6 ft (20 m) |
| Linearity (dB/dB) |
±0.05 |
| Sampling Resolution Ratio (m) |
0.4 ft to 26 ft (0.125 m to 8 m) |
| Sampling Point |
32 K |
| Distance Uncertainty (m) |
± (3.28 ft + 5 x 10^-5 x distance + sampling interval) |
| Typical Real-Time Refreshing Duration (s) |
0.2 |
| Duration of Measurement |
Defined by user, 5s, 10s, 15s, 30s, 1min, 2min, 3min are selectable |
| PON OTDR Weight |
3.3 lb. (1.5 KG) |
| Dimension (H W D) |
5.9 in x 9.3 in x 2.6 in (15 cm x 23.5 cm x 6.6 cm) |
