| Processor |
880 MHz CPU, Cortex A7 architecture |
| Operating System |
Embedded Linux OS |
| RAM |
128 MB DDR2 |
| Storage |
16 MB NorFlash |
| Network Interfaces |
1 × 10/100 Mbps LAN, 1 × 10/100 Mbps WAN |
| WiFi |
2.4 GHz, IEEE 802.11 b/g/n |
| SIM Support |
1 standard SIM card slot |
| I/O Ports |
1 × RS232, 1 × RS485, 2 × DI, 2 × DO |
| Power Supply |
9 to 48 VDC |
| Power Consumption |
< 5 Watts |
| Operating Temperature |
-13°F to 158°F (-25°C to 70°C) |
| Storage Temperature |
-40°F to 185°F (-40°C to 85°C) |
| Relative Humidity |
5% to 95% (non-condensing) |
| Antenna |
2 × SMA (1 cellular, 1 WiFi) |
| Certifications |
CE, RoHS |
| Dimensions |
3.94 × 2.36 × 1.18 in (100 × 60 × 30 mm) |
| Weight |
0.44 lb (200 g) |
