| Measuring Principle |
Dual beam absorbance method (UV254) |
| Measuring Range |
CODCr: 0 to 500 mg/L; TOC: 0 to 250 mg/L; Turbidity: 0 to 500 NTU; Water Temperature: 32°F to 122°F (0 to 50°C) |
| Measuring Accuracy |
CODCr: <5%; TOC: <5%; Turbidity: <3%; Water Temperature: ±0.36°F (0.2°C) |
| Resolution |
CODCr: 0.01 mg/L; TOC: 0.1 mg/L; Turbidity: 0.2 NTU; Water Temperature: 0.18 °F (0.1 °C) |
| Measuring Parameters |
CODCr (mg/L); TOC (mg/L); Turbidity (NTU); Water Temperature (°F). BOD, CODMn, etc., can be converted. |
| Cleaning System |
Automatic cleaning with cleaning brush (standard) |
| Protection Grade |
IP68, Maximum water depth up to 32.8 ft (10 m) |
| Cable Length |
16.4 ft (5 m) or 32.8 ft (10 m) |
| Bearing Pressure |
14.5 psi (1 bar) |
| Shell Material |
POM and 316L |
| Power Supply Voltage |
12 ± 5% VDC, Current <50mA (excluding cleaning) |
| Communication Mode |
RS485, Modbus protocol |
| Dimensions |
8.4 in x 2 in (21.4 cm x 5 cm) |
| Probe Weight |
1.47 lb (665 g) |
