Description
Technical Specification
| Radio Chains: Stream | 2 x 2.2 |
| Ethernet Ports | 10 or 100 or 1000Base-T 802.3,802.3 u,802.3ab
802.3at or af PoE PD Input Jumbo frame support (2290-byte max MTU) |
| Physical Layer Modulation Data Rate | 2.4GHz 802.11b or g or n 300Mbps
5GHz 802.11a or n or ac 867Mbps |
| Concurrent Stations | Up to 500 capable per AP |
| Simultaneous VoIP Clients | Up to 30 |
| Maximum Tx Power | 26 dBm for 2.4GHz
25 dBm for 5.0GHz |
| Channelization | 2.4GHz 802.11b or g or n 20MHz or 40 MHz
5GHz 802.11a or n or ac 20MHz or 40MHz or 80 MHz |
| BSSID | Up to 32 (27 configurable) on 2.4 GHz
Up to 16 (13 configurable) on 5 GHz |
| Power | 802.3af PoE Input (Class 3 PD) |
| Mounting Options | Wall Mount Pole Mount Diameter 1″ to 2.5″ |
| Wi-Fi Standards | 5 GHz IEEE 802.11ac 2GHz IEEE 802.11g or n |
| Degree Sector Coverage | 120 x 30 degree |
| Operating temperature range | 68 ⁰F to 131 ⁰F (20 °C to 55 °C) |
| Physical Size | 7 in x 5.9 in x 3.4 in (18 cm x 15 cm x 8.6 cm) |
