| Range |
-100kpa to 0kPa to 20kPa…100MPa |
| Power Supply |
Battery powered (3.6V,19AH) |
| Battery Service life |
6 Years for once data per hour |
| Data Transmission Interval |
Available time 2min to 1440min |
| Power Consumption |
Stand-by current≤80uA，Average data sending current≤150mA |
| Accuracy |
±0.5%FS |
| Network |
NB-IOT, 4G optional |
| Configuration Method |
USB configuration operation, server remote configuration |
| Display |
Segment LCD screen |
| Temperature Influence |
0.015%FS/℃ |
| Wake Up Method |
Buttons, timing |
| Relative Humidity |
0% to 95% |
| Sensor Material |
Sensor diaphragm 316L，shell material: stainless steel |
| Overload Pressure |
1.5 Times rated pressure |
| Protection Grade |
IP67 |
| Working Temperature |
-22°F to 158°F (-30℃ to 70℃) |
