| Temperature Range (℃) |
-60 t 450 (optional range) |
| Accuracy (℃) |
0.25 (customized), 0.5, 1.0 |
| Long-term Stability (%FS/year) |
≤0.25, ≤0.5, ≤1.0 |
| Operating Voltage (VDC) |
+15 ~ +30 (calibration value is +24) |
| Load Resistance (Ω) (4mA ~ 20mA) |
R = (U – 15) / 0.02 – RD |
| Measuring Medium |
Fluid compatible with 304 and 316L |
| Shell Material |
304, 316L |
| Protection Level |
IP65 |
| Working Environment Temperature (℃) |
-30 ~ +60 |
| Output Signal |
(4mA ~ 20mA), 0 ~ 10V, RS485, I2C |
| Response Time (10% ~ 90%) (s) |
20 (typical value) |
| Interface |
304, 316L (optional) |
