| Main Chipset |
Qualcomm Snapdragon X55 + MT7621AT |
| Max. LAN Data Rate |
1000 Mbps |
| Wi-Fi Supported Frequency |
2.4G & 5G |
| Memory |
16MB Flash + 256MB DDR3 |
| 2.4G Wi-Fi Transmission Rate |
1200 Mbps |
| 5.8G Wi-Fi Transmission Rate |
1733 Mbps |
| Standards And Wi-Fi Protocol |
IEEE 802.11ax |
| Encryption Type |
WPA2-PSK, WPA2, WPA3, WPA-PSK, WPA |
| LAN Ports |
2 |
| Function |
FireWall, QoS, VPN, SDK available |
| WAN Ports |
1 x 10 Mbps or 100 Mbps or 1000 Mbps |
| SIM Card Slot |
1 SIM Card Support |
| Interface |
1WAN+2LAN |
| Function |
Firewall, QoS, VPN, SDK available, TTL |
| 5G Wi-Fi Transmission Rate |
1733 Mbps |
| Wired Transfer Rate |
10 Mbps or 100 Mbps or 1000 |
| Ethernet |
1 x 1Gbps WAN,2 x LAN 1Gbps |
| Button |
Reset, MESH+, MESH+ LED Switch |
| DC Power Supply |
12V or 2A |
| Max Power consumption |
< 20 W |
| 5G Cellular |
5G NSA Transmission Speed: 2Gbps or 576Mbps (up to ISPs) |
| 4G Cellular |
Down 600 Mbps; UP 150 Mbps |
| Hybrid MESH+ Networking |
Wired or Wireless |
| Data Switching |
Mobile 4G or 5G Connection (Support APN) |
| Dimension |
8.268 in x 6.299 in x 1.614 in (21.0 cm x 16.0 cm x 4.1 cm) |
| Weight |
1.984 Ibs (0.9 kg) |
