Description
Features
- Type A CPU card operation supported
- WIFI+TCP/IP (POE) communication supported
- Includes buzzer and two-colour LED indicator
- Optional relay and memory features
- SOCKET interface switchable: server or client mode
- Communication interface customizable WIFI network card routing
- RFID modes: auto detect or passive read-write
Technical Specifications
| Frequency | 13.56 Mhz or 125 Khz |
| Protocol | ISO14443A or 125Khz |
| Interface Option | WIFI+TCP or IP |
| Power Supply | 9 V |
| Mount Type | Wall-mounted |
| Reading Range | 0 in to 2.76 in (0 cm to 7 cm) |
| Read Or Write | Read UID only or read write |
| Supporting Card | Mi S50 or S70 or Ultralight or TK4100 |
| Single Gross Weight | 0.88 lb (0.400 kg) |
| Dimension | 4.65 in x 2.99 in x 0.87 in (118 mm x 76 mm x 22 mm) |
