Description
Overview
125 KHz Frequency. Wiegand 26 or 34 Output Power. DC 12 V Working Voltage. 14 F to 158 F Working Temperature. 0 in to 3.93 in Reading Range.
Features
- Compact Size
- Lead Length
- Output Format
- Wide Application
- High Supply Capacity
- 125 KHz Frequency
- LED and Buzzer Indicators
Technical Specifications
| Frequency | 125 KHz |
| Support Cards | 125 KHz EM 4100 or TK 4100 |
| Working Voltage | DC 12 V |
| Working Current | 100 mA |
| Read Range | 0 in X 3.93 in (0 mm X 100 mm) |
| Protocol | EM 4100 or TK 4001 |
| Temperature | 14 °F to 158 °F (-10 °C to 70 °C) |
| Dimension | 2.08 in X 1.45 in X 0.03 in (51 mm X 37 mm X 1 mm) |
| Weight | 0.70 oz (20 g) |
