Description
Technical Specifications
| Operating System | |
| OS CPU Memory Languages support |
Windows 10 home/pro/iot Intel cherry trail Z8350 ,1.44Ghz-1.92GHz 4 GB RAM / 64 GB Flash (6+128GB optional) English, Simplified Chinese, Traditional Chinese, Japanese,Spanish, German, French, Italian, Portuguese, Korean and multiple languages |
| Hardware specification | |
| Screen size Touch panel Buttons / keypad Camera Indicator type Battery |
8-inch color 1920 x 1200 display, up to 500 nits Gorilla glass III with 10 points Capacitive Touch Screen Function Keys: Power, V+, V-, P, F, H Front 2 megapixels, rear 5 megapixels, with flash and auto focus Function LED, Speaker, Vibrator Rechargeable li-ion polymer, 8500mAh |
| Symbologies | |
| Scanner HF RFID (Optional) Laser barcode scanner High precision GNSS module (optional) |
Document and barcode scan via CAMERA Support HF/NFC Frequency 13.56Mhz ISO/IEC14443, ISO/IEC15693, MIFARE,Felica Read distance: 1.18 in to 1.96 in (3-5cm), Front Optional Sub meter level, positioning accuracy:0.25-1 seconds, support Beidou,GPS,GLONASS |
| Communication | |
| Bluetooth® WLAN WWAN GPS |
Bluetooth®4.0 Wireless LAN 802.11a/b/g/n/ac, 2.4GHz and 5GHz Dual frequency GSM: 850,900,1800,1900 MHz WCDMA: 850/1900/2100MHz LTE: B1/B2/B3/B4/B5/B7/B8/B28 TDD-LTE: B40 GPS/BDS/Glonass, error range ± 16.40 ft (5m) |
| I/O Interfaces | |
| USB POGO pin SIM slot Expansion slot RJ 45 Mini HDMI RS232 Power |
USB x2, Micro USBx1 Back 16PIN POGO PIN x1 Bottom 8PIN POGOPIN x1 Single sim slot MicroSD, up to 256 GB 10/100/1000M x1 Support Support DC 5V 3A ∮ 0.13 in (3.5 mm) power interface x1 |
| Enclosure | |
| Dimensions (W x H x D) Weight |
275x178x18mm 750g (with battery) |
| Durability | |
| Drop specification Sealing |
1.2m, 1.5m with boot case, MIL-STD 810G IP67 |
| Environmental | |
| Operating temperature Storage temperature Charging temperature Relative humidity |
-20°C to 50°C – 20°C to 70°C (without battery) 0°C to 45°C 5 % to 95 % (non-condensing) |
